This is a rare steel-framed house structure. All studs, beams, posts, and ceiling joists are prefabricated and brought to the site. All material is assembled on-site giving this particular house a very strong and energy-efficient
nature. Bottom line, a very well built house but a higher cost to build.
In cottage home Inspections, sometimes you will see some very interesting designs or methods of construction. In this case, instead of cutting the trees down to build a deck above, the owner has built the deck around these birch trees. Owners should be aware that the trees are constantly growing in height and diameter, therefore always to monitor that the deck allows the tree to grow by trimming the wood around the tree over time.
This is a new house that is being constructed with slab on grade (no basement).
The plumbing has been installed under the cement to be poured. Also under the slab, it will be a central source of heat with a pump to push the heated liquid throughout the structure. The floor will be warm, note also the styrofoam insulation complete with wire mesh which gives strength to the slab from cracking.
As can be seen here, a deck and framed wall are adjacent to each other, where water can enter into the wall cavity. Water from above roof had been splashing onto deck for many years and rotted the header, subfloor, and framing studs. I always recommend to clients when building a deck leave an air space between house and deck so that water can freely flow and not seep into framed structure.
This was a request for an inspection on a bungalow that was struck by a tornado in the Ottawa / Gatineau area in September 2018. The brick and foundation walls were inspected to determine if the brick could be saved and whether the block foundation could be rebuilt upon.
As can be seen the roof trusses were completely removed off the sills and interior walls were damaged with windows blown inward.Â Some of the brick was damaged and fell outward but the majority of the brick could be saved.
In the interior block foundation view, the foundation was in good condition for a 45-year-old, but the floor joist and subflooring had water resting on surface. Depending upon the speed of reconstruction, it was recommended that the plywood subflooring and joists may need replacing.
Poor workmanship on ceramic cutting and debris within the air ducts. Again it is advisable to go through with the home inspector and make a meticulous list. Also, even though the builders do their part to clean air ducts, it is best to get a professional air duct cleaning company.
This is a new home pre-delivery inspection. The house was supposed to be ready for the inspection, but the home had many deficiencies. It is most advisable, to have a thorough inspection done on all homes, but particularly before taking the keys to a new house, so that the deficiency list can be given to the builder to finish the house completely. As can be seen here, the exterior was not completed, the interior had many deficiencies and there was damaged areas along with dirt on the interior on this home.
This cottage home inspection showed signs in the interior of sloping floors and crooked doors. When the crawlspace area was inspected, all substructure support needed to be repaired. As can be seen, this triple built-up beam has rotted, the support column is leaning, and has no footing to stabilize the column. This situation needs to be addressed immediately as the cottage was heading toward the lake.
December 2017 and January 2018 are starting the winter with extreme cold temperatures. These windows have condensated water and ice which will eventually drip onto windowsills, wall surfaces, and onto floors. This will create mould and therefore should be dried as quickly as possible. Homeowners should monitor the situation closely in extreme cold weather.
This old Findlay manufactured in Carleton Place Ontario wood stove, is still being used in a solar powered house that was recently inspected. As a Gatineau home inspector, I have the privilege of seeing beautiful architectural components in some of my home inspections.
